HDA 0.7L Diaphragm Accumulator (100bar)
Product specifications and documentation
HDA 0.7L Diaphragm Accumulator (100bar)
Quick Specifications
Compression Ratio8:1
Gas PortM28x1.5
Designed Max. Pressure100bar
Net Weight2kg
Volume0.7L
Detailed Specifications
Technical Specifications
| Compression Ratio | 8:1 |
|---|---|
| Gas Port | M28x1.5 |
| Designed Max. Pressure | 100 bar |
| Net Weight | 2 kg |
| Volume | 0.7 L |
Dimensions
| Diameter (D) | 106 mm |
|---|---|
| Height (H) | 145 mm |
Connections
| Oil Port | G1/2(F) |
|---|
Downloads
Catalogs & Documents
Dimensional Drawings
