HDA-2.8L-250-R
Product specifications and documentation
HDA-2.8L-250-R
Quick Specifications
Accumulator TypeR
Compression Ratio4:1
Gas PortM28x1.5
Designed Max. Pressure250bar
Net Weight11kg
Detailed Specifications
Dimensions
| Diameter (D) | 178 mm |
|---|---|
| Height (H) | 266 mm |
| Dimension C (HEX) | 41 mm |
Technical specifications
| Accumulator Type | R |
|---|---|
| Compression Ratio | 4:1 |
| Gas Port | M28x1.5 |
| Designed Max. Pressure | 250 bar |
| Net Weight | 11 kg |
| Volume | 2.8 L |
Connections
| Air/Gas Port | M28x1.5 |
|---|---|
| Oil Port | G3/4HEX |
Downloads
Catalogs & Documents
Dimensional Drawings
