HBA Bladder Accumulator 42.0L 330bar

Product specifications and documentation

HBA Bladder Accumulator 42.0L 330bar
HBA-42.0L-330bar

HBA Bladder Accumulator 42.0L 330bar

HydroLync HBA Bladder Accumulator 42.0L capacity at 330 bar working pressure

Request Quote

Quick Specifications

Volume42.0 L
Working Pressure330 bar
Max Flow Rate18.0 LPS
Dimension H1135 mm

Detailed Specifications

Performance

Volume
42.0 L
Working Pressure
330 bar
Max Flow Rate
18.0 LPS

Dimensions

HBA dimension drawing
Dimension H1
135 mm
Dimension H2
102.2 mm
Shell Diameter (D)
219 mm
Total Height (H)
1612.7 mm

Technical Specifications

Max Flow Rate
18 L/sec
Designed Max. Pressure
330 bar
Net Weight
114 kg
Oil Port
G2
Gas Port
External: ø7/8"-14UNF 1A Internal: ø1/2"-20UNF 2B
Volume
42 L

Downloads

Accessories

Bladder Kit
HBA-BLADDERRequired
Gas Valve
HBA-VALVE
Permanent Gauge
HBA-GAUGE
Bushing
HBA-BUSHING
Flange
HBA-FLANGE
Support Bracket
HBA-SUPPORT-BRACKET
Mount Bracket
HBA-MOUNT-BRACKET
Clamp Band
HBA-CLAMP-BAND
N2 Charging Kit
HBA-HCB
Gas Booster
HBA-HGB
Safety Block
HBA-SAFETY-BLOCK
