HBA Bladder Accumulator 6.0L 350bar

Product specifications and documentation

HBA Bladder Accumulator 6.0L 350bar
HBA-6.0L-350bar

HBA Bladder Accumulator 6.0L 350bar

HydroLync HBA Bladder Accumulator 6.0L capacity at 350 bar working pressure

Request Quote

Quick Specifications

Volume6.0 L
Working Pressure350 bar
Max Flow Rate7.95 LPS
Dimension H178 mm

Detailed Specifications

Performance

Volume
6.0 L
Working Pressure
350 bar
Max Flow Rate
7.95 LPS

Dimensions

HBA dimension drawing
Dimension H1
78 mm
Dimension H2
65.5 mm
Shell Diameter (D)
168 mm
Total Height (H)
563 mm

Technical Specifications

Max Flow Rate
7.95 L/sec
Designed Max. Pressure
350 bar
Net Weight
20 kg
Oil Port
G1 1/4
Gas Port
External: ø7/8"-14UNF 1A Internal: ø1/2"-20UNF 2B
Volume
6 L

Downloads

Accessories

Bladder Kit
HBA-BLADDERRequired
Gas Valve
HBA-VALVE
Permanent Gauge
HBA-GAUGE
Bushing
HBA-BUSHING
Flange
HBA-FLANGE
Support Bracket
HBA-SUPPORT-BRACKET
Mount Bracket
HBA-MOUNT-BRACKET
Clamp Band
HBA-CLAMP-BAND
N2 Charging Kit
HBA-HCB
Gas Booster
HBA-HGB
Safety Block
HBA-SAFETY-BLOCK
