HLA2 04-2 AC Motor Cooler
Product specifications and documentation
HLA2 04-2 AC Motor Cooler
HydroLync HLA2 04-2 AC motor driven air-oil cooler with 2-pole motor
Quick Specifications
Cooling Capacity0.12kW/°C
Heat Dissipation4.8kW
Heat Dissipation (kcal)4,128kcal/h
Max Flow Rate100L/min
Motor Poles2
Detailed Specifications
Performance
| Cooling Capacity | 0.12 kW/°C |
|---|---|
| Heat Dissipation | 4.8 kW |
| Heat Dissipation (kcal) | 4,128 kcal/h |
| Max Flow Rate | 100 L/min |
| Motor Poles | 2 |
Dimensions
| Bracket Hole | 4x(Ø10x19) |
|---|---|
| Depth (D) | 180 mm |
| Dimension E | 63 mm |
| Dimension F | 90 mm |
| Dimension G | 105 mm |
| Dimension H | 164 mm |
| Dimension I | 133 mm |
| Dimension J | 134 mm |
| Dimension K | 195 mm |
| Height (C) | 271 mm |
| Length (A) | 266 mm |
| Width (B) | 273 mm |
Electrical
| AC Motor Type | Three Phase |
|---|---|
| Motor Type | 2-Pole AC Motor |
Downloads
Catalogs & Documents
HLA2 Series Selection Guide 2026 V04EN
Air Oil Cooler Series User Manual 2026KO
HLA2 Series Selection Guide 2026 V04KO
HLA2 Series Selection Guide 2026 V04ZH
HydroLync Complete Selection Guide 2026 V05 (EN)EN
HydroLync Complete Selection Guide 2026 V05 (KR)KO
HydroLync Complete Selection Guide 2026 V05 (CN)ZH
Dimensional Drawings
