HLA2 HC V58-4 Air Oil Cooler (Special Type)

Product specifications and documentation

HLA2 HC V58-4 Air Oil Cooler (Special Type)

HLA2 HC V58-4 Air Oil Cooler (Special Type)

Request Quote

Quick Specifications

Cooling Capacity1.7kW/°C
Heat Dissipation68kW
Heat Dissipation (kcal)58,480kcal/h
Max Flow Rate400L/min
Motor Poles6

Detailed Specifications

Performance
Cooling Capacity1.7 kW/°C
Heat Dissipation68 kW
Heat Dissipation (kcal)58,480 kcal/h
Max Flow Rate400 L/min
Motor Poles6
Dimensions
HLA2 dimension drawing
Depth (D)639 mm
Height (C)928 mm
Length (A)868 mm
Net Weight89 kg
Width (B)868 mm
Electrical
Motor Type6-Pole AC Motor

Downloads

Accessories

DTM Digital Thermometer
DTM
Thermal Switch (DIN Connector)
TS-DIN
Thermal Switch (Wire Connector)
TS-WIRE
Matrix Stone Guard
STONE-GUARD
Matrix Dust Guard
DUST-GUARD
Matrix Dust + Stone Guard
COMBO-GUARD
