HLA2 R35-6 Air Oil Cooler
Product specifications and documentation
HLA2 R35-6 Air Oil Cooler
Quick Specifications
Cooling Capacity1.2kW/°C
Heat Dissipation48kW
Heat Dissipation (kcal)41,280kcal/h
Max Flow Rate350L/min
Motor Poles6
Detailed Specifications
Performance
| Cooling Capacity | 1.2 kW/°C |
|---|---|
| Heat Dissipation | 48 kW |
| Heat Dissipation (kcal) | 41,280 kcal/h |
| Max Flow Rate | 350 L/min |
| Motor Poles | 6 |
Dimensions
| Depth (D) | 559 mm |
|---|---|
| Height (C) | 742 mm |
| Length (A) | 692 mm |
| Net Weight | 55 kg |
| Width (B) | 692 mm |
Electrical
| Motor Type | 6-Pole AC Motor |
|---|
Environmental
| Noise Level | 76 dB |
|---|
