HLA2 V07-4
Product specifications and documentation
HLA2 V07-4
Quick Specifications
Cooling Capacity0.15kW/°C
Heat Dissipation6kW
Heat Dissipation (kcal)5,160kcal/h
Max Flow Rate125L/min
Motor Poles4
Detailed Specifications
Performance
| Cooling Capacity | 0.15 kW/°C |
|---|---|
| Heat Dissipation | 6 kW |
| Heat Dissipation (kcal) | 5,160 kcal/h |
| Max Flow Rate | 125 L/min |
| Motor Poles | 4 |
Dimensions
| Depth (D) | 397.5 mm |
|---|---|
| Dimension F | 160 mm |
| Dimension H | 270 mm |
| Dimension I | 145 mm |
| Dimension J | 297 mm |
| Dimension K | 305 mm |
| Height (C) | 407.5 mm |
| Length (A) | 365 mm |
| Net Weight | 19 kg |
| Width (B) | 365 mm |
Electrical
| Motor Type | 4-Pole AC Motor |
|---|
