HLA2 V113-6
Product specifications and documentation
HLA2 V113-6
Quick Specifications
Cooling Capacity4.2kW/°C
Heat Dissipation168kW
Heat Dissipation (kcal)144,480kcal/h
Max Flow Rate500L/min
Motor Poles6
Detailed Specifications
Performance
| Cooling Capacity | 4.2 kW/°C |
|---|---|
| Heat Dissipation | 168 kW |
| Heat Dissipation (kcal) | 144,480 kcal/h |
| Max Flow Rate | 500 L/min |
| Motor Poles | 6 |
Dimensions
| Depth (D) | 788 mm |
|---|---|
| Dimension F | 985 mm |
| Dimension H | 665 mm |
| Dimension I | 550 mm |
| Dimension J | 1,115 mm |
| Dimension K | 1,177 mm |
| Height (C) | 1,285 mm |
| Length (A) | 1,205 mm |
| Net Weight | 250 kg |
| Width (B) | 1,185 mm |
Electrical
| Motor Type | 6-Pole AC Motor |
|---|
