HLA2 V23-4
Product specifications and documentation
HLA2 V23-4
Quick Specifications
Cooling Capacity0.8kW/°C
Heat Dissipation32kW
Heat Dissipation (kcal)27,520kcal/h
Max Flow Rate200L/min
Motor Poles4
Detailed Specifications
Performance
| Cooling Capacity | 0.8 kW/°C |
|---|---|
| Heat Dissipation | 32 kW |
| Heat Dissipation (kcal) | 27,520 kcal/h |
| Max Flow Rate | 200 L/min |
| Motor Poles | 4 |
Dimensions
| Depth (D) | 473.5 mm |
|---|---|
| Dimension F | 378 mm |
| Dimension H | 330 mm |
| Dimension I | 220 mm |
| Dimension J | 520 mm |
| Dimension K | 528 mm |
| Height (C) | 629 mm |
| Length (A) | 579 mm |
| Net Weight | 39 kg |
| Width (B) | 579 mm |
Electrical
| Motor Type | 4-Pole AC Motor |
|---|
