HLD-07-24V-W50-DMC
Product specifications and documentation
HLD-07-24V-W50-DMC
Quick Specifications
Cooling Capacity0.19kW/°C
Heat Dissipation (kW)7.6kW
Heat Dissipation (kcal/h)6,536kcal/h
Max Flow Rate125LPM
Motor RPM3,060RPM
Detailed Specifications
Performance
| Cooling Capacity | 0.19 kW/°C |
|---|---|
| Heat Dissipation (kW) | 7.6 kW |
| Heat Dissipation (kcal/h) | 6,536 kcal/h |
| Max Flow Rate | 125 LPM |
| Motor RPM | 3,060 RPM |
| Noise Level | 74 dBA |
| Oil Flow (Max) | Max. 130 LPM |
| Working Pressure (Max) | 14 bar |
Dimensions
| Length (A) | 340 mm |
|---|---|
| Width (B) | 340 mm |
| Height (C) | 335 mm |
| Depth (D) | 198 mm |
| Dimension E | 63 mm |
| Dimension F | 160 mm |
| Dimension G | 94 mm |
| Dimension H | 120 mm |
| Dimension I | 90 mm |
| Dimension J | 300 mm |
| Dimension K | 254 mm |
| Net Weight | 9 kg |
| Bracket Hole | 11x22 |
Electrical
| DC Voltage | 12V/24 V |
|---|---|
| 12V Motor Specs | 12V / 20A @3,060rpm |
| 24V Motor Specs | 24V / 10A @3,060rpm |
| Insulation Class | H (180℃/356℉) |
