HLH2 110 Hydraulic Motor Cooler
Product specifications and documentation
HLH2 110 Hydraulic Motor Cooler
Quick Specifications
Cooling Capacity2.37kW/°C
Heat Dissipation (kcal/h)81,528kcal/h
Heat Dissipation94kW
Max Speed1,440rpm
Detailed Specifications
Performance
| Cooling Capacity | 2.37 kW/°C |
|---|---|
| Heat Dissipation (kcal/h) | 81,528 kcal/h |
| Heat Dissipation | 94 kW |
| Max Speed | 1,440 rpm |
Dimensions
| Net Weight | 117 kg |
|---|---|
| Length (A) | 1,205 mm |
| Width (B) | 1,185 mm |
| Height (C) | 1,285 mm |
| Depth (D) | 460 mm |
| Dimension E | 63 mm |
| Dimension F | 985 mm |
| Dimension G | 192 mm |
| Dimension H | 665 mm |
| Dimension I | 550 mm |
| Dimension J | 1,115 mm |
| Dimension K | 1,177 mm |
| Dimension L | 666 mm |
| Mounting Slot | ø14x94 / ø14x23 |
Hydraulic Motor
| Max Flow Rate | 400 L/min |
|---|---|
| Oil Port (P1/P2/P3) | G2" |
Downloads
Catalogs & Documents
HLH2 Series Selection Guide 2026 V04EN
Air Oil Cooler Series User Manual 2026KO
HLH2 Series Selection Guide 2026 V04KO
HLH2 Series Selection Guide 2026 V04ZH
HydroLync Complete Selection Guide 2026 V05 (EN)EN
HydroLync Complete Selection Guide 2026 V05 (KR)KO
HydroLync Complete Selection Guide 2026 V05 (CN)ZH
Dimensional Drawings
