HLH2 78 Hydraulic Motor Cooler
Product specifications and documentation
HLH2 78 Hydraulic Motor Cooler
Quick Specifications
Cooling Capacity2.25kW/°C
Heat Dissipation (kcal/h)77,400kcal/h
Heat Dissipation90kW
Max Speed1,690rpm
Detailed Specifications
Performance
| Cooling Capacity | 2.25 kW/°C |
|---|---|
| Heat Dissipation (kcal/h) | 77,400 kcal/h |
| Heat Dissipation | 90 kW |
| Max Speed | 1,690 rpm |
Dimensions
| Net Weight | 111 kg |
|---|---|
| Length (A) | 1,022 mm |
| Width (B) | 1,022 mm |
| Height (C) | 1,092 mm |
| Depth (D) | 460 mm |
| Dimension E | 83 mm |
| Dimension F | 821 mm |
| Dimension G | 176 mm |
| Dimension H | 455 mm |
| Dimension I | 325 mm |
| Dimension J | 972 mm |
| Dimension K | 997 mm |
| Dimension L | 565 mm |
| Mounting Slot | ø14x94 / ø14x23 |
Hydraulic Motor
| Max Flow Rate | 500 L/min |
|---|---|
| Oil Port (P1/P2/P3) | G2" |
