HLO3 07-4-60L Circulation Pump Cooler
Product specifications and documentation
HLO3 07-4-60L Circulation Pump Cooler
Quick Specifications
Oil Flow (1710 RPM)70L/min
Pump Displacement41cc/rev
Max Oil Flow Rate70L/min
Pump Inlet Port (P4)G 1 1/2"
Detailed Specifications
Performance
| Oil Flow (1710 RPM) | 70 L/min |
|---|---|
| Pump Displacement | 41 cc/rev |
| Max Oil Flow Rate | 70 L/min |
| Pump Inlet Port (P4) | G 1 1/2" |
Dimensions
| Dim A (Width) | 365 mm |
|---|---|
| Dim B (Height) | 365 mm |
| Dim C (Depth incl. fan) | 405 mm |
| Dim D (Motor center) | 582 mm |
| Dim E (Port offset) | 63 mm |
| Dim F (Matrix width) | 160 mm |
| Dim G (Fan clearance) | 143 mm |
| Dim H (Mount height) | 385 mm |
| Dim I (Mount depth) | 295 mm |
| Dim J (Foot spacing X) | 230 mm |
| Dim K (Foot spacing Y) | 303 mm |
| Dim L (Port center) | 225 mm |
| Mounting Slot Hole | O10x90 / O10x19 |
| Oil Port P1/P2/P3 | G1" |
Electrical
| Motor Power | 2.2 kW |
|---|---|
| Voltage | 220/380/440 V |
Hydraulic
| Oil Port (P1/P2/P3) | G1" |
|---|---|
| Port P4 | G 1 1/2" |
Thermal
| Cooling Capacity | 0.21 kW/°C |
|---|---|
| Heat Dissipation (kcal/h) | 7,224 kcal/h |
| Heat Dissipation (kW) | 8.4 kW |
Environmental
| Noise Level | 65 dB(A) |
|---|
Mechanical
| Motor Frame | 90L |
|---|---|
| Weight | 33.5 kg |
Downloads
Catalogs & Documents
HLO3 Series Selection Guide 2026 V05EN
Air Oil Cooler Series User Manual 2026KO
HLO3 Series Selection Guide 2026 V05KO
HLO3 Series Selection Guide 2026 V05ZH
HydroLync Complete Selection Guide 2026 V05 (EN)EN
HydroLync Complete Selection Guide 2026 V05 (KR)KO
HydroLync Complete Selection Guide 2026 V05 (CN)ZH
Dimensional Drawings
