HLA2 015-2 AC Motor Cooler
HLA2-015-2

HLA2 015-2 AC Motor Cooler

HydroLync HLA2 015-2 AC motor driven air-oil cooler with 2-pole motor

Request Quote

Quick Specifications

Cooling Capacity0.048 kW/°C
Heat Dissipation1.92 kW
Heat Dissipation (kcal)1651 kcal/h
Max Flow Rate40 L/min

Detailed Specifications

Performance

Cooling Capacity
0.048 kW/°C
Heat Dissipation
1.92 kW
Heat Dissipation (kcal)
1651 kcal/h
Max Flow Rate
40 L/min
Motor Poles
2

Dimensions

HLA2 dimension drawing
Bracket Hole
4xØ6
Depth (D)
100 mm
Dimension E
45 mm
Dimension F
72 mm
Dimension G
69 mm
Dimension H
100 mm
Dimension I
30 mm
Dimension J
138 mm
Height (C)
175 mm
Length (A)
175 mm
Width (B)
176 mm

Electrical

AC Motor Type
Single Phase
Motor Type
2-Pole AC Motor

Downloads

Accessories

DTM Digital Thermometer
DTM
Thermal Switch (DIN Connector)
TS-DIN
Thermal Switch (Wire Connector)
TS-WIRE
Matrix Stone Guard
STONE-GUARD
Matrix Dust Guard
DUST-GUARD
Matrix Dust + Stone Guard
COMBO-GUARD
