HLA2 56-6 AC Motor Cooler

Product specifications and documentation

HLA2 56-6 AC Motor Cooler
HLA2-56-6

HLA2 56-6 AC Motor Cooler

HydroLync HLA2 56-6 AC motor driven air-oil cooler with 6-pole motor

Request Quote

Quick Specifications

Cooling Capacity1.45 kW/°C
Heat Dissipation58 kW
Heat Dissipation (kcal)49880 kcal/h
Max Flow Rate300 L/min

Detailed Specifications

Performance

Cooling Capacity
1.45 kW/°C
Heat Dissipation
58 kW
Heat Dissipation (kcal)
49880 kcal/h
Max Flow Rate
300 L/min
Motor Poles
6

Dimensions

HLA2 dimension drawing
Depth (D)
619 mm
Dimension E
63 mm
Dimension F
664 mm
Dimension G
163 mm
Dimension H
430 mm
Dimension I
320 mm
Dimension J
796 mm
Dimension K
827 mm
Height (C)
928 mm
Length (A)
868 mm
Net Weight
73 kg
Mounting Slot
ø12x92 ø12x21
Width (B)
868 mm

Electrical

Motor Type
6-Pole AC Motor

Downloads

Accessories

DTM Digital Thermometer
DTM
Thermal Switch (DIN Connector)
TS-DIN
Thermal Switch (Wire Connector)
TS-WIRE
Matrix Stone Guard
STONE-GUARD
Matrix Dust Guard
DUST-GUARD
Matrix Dust + Stone Guard
COMBO-GUARD
