HLA2 V78-6

Product specifications and documentation

HLA2 V78-6
HLA2-V78-6

HLA2 V78-6

Request Quote

Quick Specifications

Cooling Capacity2.25 kW/°C
Heat Dissipation90 kW
Heat Dissipation (kcal)77400 kcal/h
Max Flow Rate500 L/min

Detailed Specifications

Performance

Cooling Capacity
2.25 kW/°C
Heat Dissipation
90 kW
Heat Dissipation (kcal)
77400 kcal/h
Max Flow Rate
500 L/min
Motor Poles
6

Dimensions

HLA2 dimension drawing
Depth (D)
662 mm
Dimension F
821 mm
Dimension H
455 mm
Dimension I
325 mm
Dimension J
972 mm
Dimension K
997 mm
Height (C)
1092 mm
Length (A)
1022 mm
Net Weight
135 kg
Width (B)
1022 mm

Electrical

Motor Type
6-Pole AC Motor

Downloads

Accessories

DTM Digital Thermometer
DTM
Thermal Switch (DIN Connector)
TS-DIN
Thermal Switch (Wire Connector)
TS-WIRE
Matrix Stone Guard
STONE-GUARD
Matrix Dust Guard
DUST-GUARD
Matrix Dust + Stone Guard
COMBO-GUARD
