HLD-16-24V-W50-DMC

Product specifications and documentation

HLD-16-24V-W50-DMC
HLD-16-24V-W50-DMC

HLD-16-24V-W50-DMC

Request Quote

Quick Specifications

Cooling Capacity0.39 kW/°C
Heat Dissipation (kW)15.6 kW
Heat Dissipation (kcal/h)13416 kcal/h
Max Flow Rate200 LPM

Detailed Specifications

Performance

Cooling Capacity
0.39 kW/°C
Heat Dissipation (kW)
15.6 kW
Heat Dissipation (kcal/h)
13416 kcal/h
Max Flow Rate
200 LPM
Motor RPM
3060 RPM
Noise Level
74 dBA
Oil Flow (Max)
Max. 200 LPM
Working Pressure (Max)
14 bar

Dimensions

HLD dimension drawing
Length (A)
466 mm
Width (B)
466 mm
Height (C)
470 mm
Depth (D)
218 mm
Dimension E
63 mm
Dimension F
296 mm
Dimension G
92 mm
Dimension H
140 mm
Dimension I
100 mm
Dimension J
416 mm
Dimension K
388 mm
Net Weight
15 kg
Bracket Hole
11x22

Electrical

DC Voltage
12V/24V V
12V Motor Specs
12V / 20A @3,060rpm
24V Motor Specs
24V / 10A @3,060rpm
Insulation Class
H (180℃/356℉)

Downloads

Accessories

DMC Motor Controller
DMC
iDMC Intelligent Motor Controller
iDMC
DTM Digital Thermometer
DTM
Thermal Switch (DIN Connector)
TS-DIN
Thermal Switch (Wire Connector)
TS-WIRE
Matrix Stone Guard
STONE-GUARD
Matrix Dust Guard
DUST-GUARD
Matrix Dust + Stone Guard
COMBO-GUARD
