HLD-V35-24V-W50

Product specifications and documentation

HLD-V35-24V-W50
HLD-V35-24V-W50

HLD-V35-24V-W50

Request Quote

Quick Specifications

Cooling Capacity0.81 kW/°C
Heat Dissipation (kW)32.4 kW
Heat Dissipation (kcal/h)27864 kcal/h
Max Flow Rate350 LPM

Detailed Specifications

Performance

Cooling Capacity
0.81 kW/°C
Heat Dissipation (kW)
32.4 kW
Heat Dissipation (kcal/h)
27864 kcal/h
Max Flow Rate
350 LPM
Motor RPM
3060 RPM
Noise Level
77 dBA
Oil Flow (Max)
Max. 350 LPM
Working Pressure (Max)
14 bar

Dimensions

HLD dimension drawing
Length (A)
690 mm
Width (B)
680 mm
Height (C)
720 mm
Depth (D)
238 mm
Dimension E
83 mm
Dimension F
482 mm
Dimension G
136 mm
Dimension H
320 mm
Dimension I
280 mm
Dimension J
356 mm
Dimension K
618 mm
Net Weight
34 kg
Bracket Hole
12x22

Electrical

DC Voltage
12V/24V V
12V Motor Specs
12V / 2×20A @3,060rpm
24V Motor Specs
24V / 2×10A @3,060rpm
Insulation Class
H (180℃/356℉)
