HLH2 113 Hydraulic Motor Cooler

Product specifications and documentation

HLH2 113 Hydraulic Motor Cooler
HLH2-113

HLH2 113 Hydraulic Motor Cooler

Request Quote

Quick Specifications

Cooling Capacity4.2 kW/°C
Heat Dissipation (kcal/h)144480 kcal/h
Heat Dissipation170.8 kW
Max Speed1440 rpm

Detailed Specifications

Performance

Cooling Capacity
4.2 kW/°C
Heat Dissipation (kcal/h)
144480 kcal/h
Heat Dissipation
170.8 kW
Max Speed
1440 rpm

Dimensions

HLH2 dimension drawing
Net Weight
184 kg
Length (A)
1205 mm
Width (B)
1185 mm
Height (C)
1285 mm
Depth (D)
510 mm
Dimension E
113 mm
Dimension F
985 mm
Dimension G
192 mm
Dimension H
665 mm
Dimension I
550 mm
Dimension J
1115 mm
Dimension K
1177 mm
Dimension L
666 mm
Mounting Slot
ø14x94 / ø14x23

Hydraulic Motor

Max Flow Rate
500 L/min
Oil Port (P1/P2/P3)
G2"

Downloads

Accessories

Thermal Switch (DIN Connector)
TS-DIN
Thermal Switch (Wire Connector)
TS-WIRE
Matrix Stone Guard
STONE-GUARD
Matrix Dust Guard
DUST-GUARD
Matrix Dust + Stone Guard
COMBO-GUARD
