HLO3 07-4-40L Circulation Pump Cooler

Product specifications and documentation

HLO3 07-4-40L Circulation Pump Cooler
HLO3-07-4-40L

HLO3 07-4-40L Circulation Pump Cooler

Request Quote

Quick Specifications

Oil Flow (1710 RPM)47 L/min
Pump Displacement27.5 cc/rev
Max Oil Flow Rate47 L/min
Pump Inlet Port (P4)G 1 1/2"

Detailed Specifications

Performance

Oil Flow (1710 RPM)
47 L/min
Pump Displacement
27.5 cc/rev
Max Oil Flow Rate
47 L/min
Pump Inlet Port (P4)
G 1 1/2"

Dimensions

Dim A (Width)
365 mm
Dim B (Height)
365 mm
Dim C (Depth incl. fan)
405 mm
Dim D (Motor center)
582 mm
Dim E (Port offset)
63 mm
Dim F (Matrix width)
160 mm
Dim G (Fan clearance)
143 mm
Dim H (Mount height)
385 mm
Dim I (Mount depth)
295 mm
Dim J (Foot spacing X)
230 mm
Dim K (Foot spacing Y)
303 mm
Dim L (Port center)
225 mm
Mounting Slot Hole
O10x90 / O10x19
Oil Port P1/P2/P3
G1"

Electrical

Motor Power
2.2 kW
Voltage
220/380/440V V

Hydraulic

Oil Port (P1/P2/P3)
G1"
Port P4
G 1 1/2"

Thermal

Cooling Capacity
0.17 kW/°C
Heat Dissipation (kcal/h)
5848 kcal/h
Heat Dissipation (kW)
6.8 kW

Environmental

Noise Level
65 dB(A)

Mechanical

Motor Frame
90L
Weight
33.5 kg

Downloads

Accessories

Thermal Switch (DIN Connector)
TS-DIN
Thermal Switch (Wire Connector)
TS-WIRE
Matrix Stone Guard
STONE-GUARD
Matrix Dust Guard
DUST-GUARD
Matrix Dust + Stone Guard
COMBO-GUARD
