HLO3 16-4-20L Circulation Pump Cooler

Product specifications and documentation

HLO3 16-4-20L Circulation Pump Cooler
HLO3-16-4-20L

HLO3 16-4-20L Circulation Pump Cooler

Request Quote

Quick Specifications

Oil Flow (1710 RPM)24 L/min
Pump Displacement13.8 cc/rev
Max Oil Flow Rate24 L/min
Pump Inlet Port (P4)G 1 1/2"

Detailed Specifications

Performance

Oil Flow (1710 RPM)
24 L/min
Pump Displacement
13.8 cc/rev
Max Oil Flow Rate
24 L/min
Pump Inlet Port (P4)
G 1 1/2"

Dimensions

HLO3 dimension drawing
Dim A (Width)
496 mm
Dim B (Height)
496 mm
Dim C (Depth incl. fan)
536 mm
Dim D (Motor center)
610 mm
Dim E (Port offset)
63 mm
Dim F (Matrix width)
296 mm
Dim G (Fan clearance)
143 mm
Dim H (Mount height)
410 mm
Dim I (Mount depth)
310 mm
Dim J (Foot spacing X)
230 mm
Dim K (Foot spacing Y)
439 mm
Dim L (Port center)
290 mm
Mounting Slot Hole
O10x90 / O10x19
Oil Port P1/P2/P3
G1"

Electrical

Motor Power
2.2 kW
Voltage
220/380/440V V

Downloads

Accessories

Thermal Switch (DIN Connector)
TS-DIN
Thermal Switch (Wire Connector)
TS-WIRE
Matrix Stone Guard
STONE-GUARD
Matrix Dust Guard
DUST-GUARD
Matrix Dust + Stone Guard
COMBO-GUARD
