HLO3 35-4-40L Circulation Pump Cooler

Product specifications and documentation

HLO3 35-4-40L Circulation Pump Cooler
HLO3-35-4-40L

HLO3 35-4-40L Circulation Pump Cooler

Request Quote

Quick Specifications

Oil Flow (1710 RPM)47 L/min
Pump Displacement27.5 cc/rev
Max Oil Flow Rate47 L/min
Pump Inlet Port (P4)G 1 1/2"

Detailed Specifications

Performance

Oil Flow (1710 RPM)
47 L/min
Pump Displacement
27.5 cc/rev
Max Oil Flow Rate
47 L/min
Pump Inlet Port (P4)
G 1 1/2"

Dimensions

HLO3 dimension drawing
Dim A (Width)
692 mm
Dim B (Height)
692 mm
Dim C (Depth incl. fan)
742 mm
Dim D (Motor center)
754 mm
Dim E (Port offset)
83 mm
Dim F (Matrix width)
482 mm
Dim G (Fan clearance)
157 mm
Dim H (Mount height)
534 mm
Dim I (Mount depth)
434 mm
Dim J (Foot spacing X)
260 mm
Dim K (Foot spacing Y)
649 mm
Dim L (Port center)
398 mm
Mounting Slot Hole
O10x90 / O10x19
Oil Port P1/P2/P3
G1 1/2"

Electrical

Motor Power
4 kW
Voltage
220/380/440V V

Downloads

Accessories

Thermal Switch (DIN Connector)
TS-DIN
Thermal Switch (Wire Connector)
TS-WIRE
Matrix Stone Guard
STONE-GUARD
Matrix Dust Guard
DUST-GUARD
Matrix Dust + Stone Guard
COMBO-GUARD
