HOC1-14-1460-PKJ
Product specifications and documentation
HOC1-14-1460-PKJ
Quick Specifications
Max Working Pressure (Oil)10bar
Max Working Pressure (Water)10bar
Test Pressure15bar
Detailed Specifications
Performance
| Flow Rate (Oil) | 1300 L/min |
| Flow Rate (Water) | 500 L/min |
| Heat Dissipation | 129000 kcal/h |
| Heat Transfer Area | 77.9 m² |
Hydraulic
| Max Working Pressure (Oil) | 10 bar |
| Max Working Pressure (Water) | 10 bar |
| Test Pressure | 15 bar |
Thermal
| Max Working Temperature | 50 °C |
